interval - ALIX + Navisys GR-701W (USB)
Report generated: Fri Nov 30 17:04:05 2018 UTCStart Time: Thu Nov 29 17:04:00 2018 UTC
End Time: Fri Nov 30 17:04:00 2018 UTC
Report Period: 1.0 days
Warning: plots clipped
Tech Solvency / NTP / Servers / interval / all graphs
About this server | other servers
UTC (according to your browser):
- Local Clock Time/Frequency Offsets
- Local RMS Time Jitter
- Local RMS Frequency Jitter
- Local Clock Time Offset Histogram
- Local GPS
- Peer Offsets
- Peer Offset 166.70.136.35
- Peer Offset 17.254.0.49
- Peer Offset 199.102.46.72
- Peer Offset 209.165.131.20
- Peer Offset 209.193.63.10
- Peer Offset 209.193.63.100
- Peer Offset 209.193.63.123
- Peer Offset 216.218.254.202
- Peer Offset 31.207.56.54
- Peer Offset 31.207.56.55
- Refclock Offset SHM(0)
- Refclock Offset SHM(1)
- Peer Jitters
- Peer Jitter 166.70.136.35
- Peer Jitter 17.254.0.49
- Peer Jitter 199.102.46.72
- Peer Jitter 209.165.131.20
- Peer Jitter 209.193.63.10
- Peer Jitter 209.193.63.100
- Peer Jitter 209.193.63.123
- Peer Jitter 216.218.254.202
- Peer Jitter 31.207.56.54
- Peer Jitter 31.207.56.55
- Refclock RMS Jitter SHM(0)
- Refclock RMS Jitter SHM(1)
- Summary
Local Clock Time/Frequency Offsets
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Local Clock Time Offset | -474.704 | -451.747 | -435.970 | -12.489 | 375.710 | 462.403 | 509.922 | 811.680 | 914.150 | 288.094 | -0.115 | µs | -4.15 | 9.24 | |||
| Local Clock Frequency Offset | 115.436 | 115.497 | 115.555 | 115.791 | 115.935 | 115.978 | 116.049 | 0.380 | 0.481 | 0.117 | 115.768 | ppm | 9.576e+08 | 9.438e+11 | |||
The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.
These are fields 3 (time) and 4 (frequency) from the loopstats log file.
Local RMS Time Jitter
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Local RMS Time Jitter | 400.417 | 416.193 | 429.520 | 467.885 | 503.632 | 514.205 | 526.344 | 74.112 | 98.012 | 22.635 | 467.091 | µs | 7629 | 1.51e+05 | |||
This shows the RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.
Lower is better. An ideal system would be a horizontal line at 0μs.
RMS jitter is field 5 in the loopstats log file.
Local RMS Frequency Jitter
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Local RMS Frequency Jitter | 61.177 | 63.772 | 65.618 | 70.038 | 75.524 | 76.868 | 79.317 | 9.906 | 13.096 | 2.976 | 70.284 | ppb | 1.163e+04 | 2.646e+05 | |||
This shows the RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.
Lower is better. An ideal clock would be a horizontal line at 0ppm.
RMS Frequency Jitter is field 6 in the loopstats log file.
Local Clock Time Offset Histogram
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Local Clock Offset | -474.704 | -451.747 | -435.970 | -12.489 | 375.710 | 462.403 | 509.922 | 811.680 | 914.150 | 288.094 | -0.115 | µs | -4.15 | 9.24 | |||
This shows the clock offsets of the local clock as a histogram.
The Local Clock Offset is field 3 from the loopstats log file.
Peer Offsets
This shows the offset of all refclocks, peers and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.
Clock Offset is field 5 in the peerstats log file.
Peer Offset 13.65.88.161
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 13.65.88.161 | -5.477 | -0.812 | 0.492 | 2.716 | 4.878 | 5.720 | 5.780 | 4.387 | 6.531 | 1.379 | 2.687 | ms | 2.953 | 9.808 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 133.243.238.243
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 133.243.238.243 | -3.148 | -3.037 | -2.675 | 1.288 | 5.479 | 5.786 | 5.917 | 8.153 | 8.824 | 1.833 | 1.329 | ms | -0.6802 | 5.18 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 166.70.136.35
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 166.70.136.35 | -1.856 | -1.634 | -0.999 | 1.550 | 4.095 | 4.743 | 5.128 | 5.093 | 6.377 | 1.421 | 1.471 | ms | 0.231 | 2.998 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 17.253.2.125
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 17.253.2.125 | -2.824 | 0.326 | 0.615 | 1.305 | 2.236 | 2.669 | 3.028 | 1.621 | 2.343 | 0.578 | 1.320 | ms | 4.212 | 20.02 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 17.254.0.49
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 17.254.0.49 | 0.594 | 0.708 | 0.984 | 1.636 | 2.451 | 2.690 | 2.715 | 1.468 | 1.982 | 0.437 | 1.667 | ms | 30.88 | 114.9 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 192.168.254.55
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 192.168.254.55 | 1.286 | 1.300 | 1.335 | 1.405 | 1.496 | 1.517 | 1.523 | 0.161 | 0.217 | 0.048 | 1.409 | ms | 2.28e+04 | 6.481e+05 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 194.58.200.20
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 194.58.200.20 | -1.119 | -1.066 | -0.971 | -0.614 | -0.121 | 0.019 | 0.143 | 0.850 | 1.085 | 0.251 | -0.588 | ms | -46.95 | 189.6 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 199.102.46.72
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 199.102.46.72 | -34.723 | -19.959 | -1.953 | -1.164 | -0.519 | -0.330 | -0.266 | 1.433 | 19.628 | 3.012 | -1.603 | ms | -15.91 | 137 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 209.165.131.20
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 209.165.131.20 | -3.688 | -3.484 | -2.834 | -0.419 | 1.960 | 3.328 | 4.292 | 4.794 | 6.812 | 1.493 | -0.448 | ms | -5.89 | 14.78 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 209.193.63.10
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 209.193.63.10 | 0.311 | 0.453 | 0.629 | 1.481 | 2.480 | 5.369 | 8.577 | 1.851 | 4.917 | 0.879 | 1.572 | ms | 6.484 | 40.13 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 209.193.63.100
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 209.193.63.100 | 0.814 | 0.856 | 1.091 | 1.631 | 2.237 | 2.410 | 2.511 | 1.146 | 1.553 | 0.367 | 1.627 | ms | 51.02 | 214.7 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 209.193.63.123
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 209.193.63.123 | 0.797 | 0.892 | 0.996 | 1.353 | 1.869 | 2.161 | 2.325 | 0.873 | 1.269 | 0.260 | 1.396 | ms | 97.58 | 498 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 216.218.254.202
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 216.218.254.202 | 0.350 | 0.482 | 0.579 | 1.319 | 2.847 | 3.063 | 3.234 | 2.268 | 2.581 | 0.772 | 1.596 | ms | 4.826 | 11.62 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 31.207.56.54
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 31.207.56.54 | -0.349 | 0.048 | 0.207 | 0.732 | 1.205 | 1.384 | 1.502 | 0.998 | 1.335 | 0.311 | 0.729 | ms | 6.355 | 16.39 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Peer Offset 31.207.56.55
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Offset 31.207.56.55 | -0.517 | -0.235 | 0.015 | 0.685 | 1.221 | 1.476 | 1.583 | 1.206 | 1.711 | 0.366 | 0.660 | ms | 2.729 | 6.426 | |||
This shows the offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.
The chart also plots offset±rtt. Where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.
Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats file.
Refclock Offset SHM(0)
.png)
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Refclock Offset SHM(0) | -22.349 | -17.520 | -13.372 | -3.344 | 6.506 | 9.209 | 14.215 | 19.878 | 26.729 | 6.189 | -3.179 | ms | -8.131 | 22.17 | |||
This shows the offset of a local refclock in seconds. This is useful to see how the measured offset is behaving.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90%% ranges may be: local serial GPS 200 ms; local PPS 20µs.
Clock Offset is field 5 in the peerstats log file.
Refclock Offset SHM(1)
.png)
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Refclock Offset SHM(1) | -474.705 | -451.748 | -435.971 | -12.490 | 375.711 | 462.404 | 509.923 | 811.682 | 914.152 | 288.094 | -0.115 | µs | -4.15 | 9.24 | |||
This shows the offset of a local refclock in seconds. This is useful to see how the measured offset is behaving.
Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90%% ranges may be: local serial GPS 200 ms; local PPS 20µs.
Clock Offset is field 5 in the peerstats log file.
Peer Jitters
This shows the RMS Jitter of all refclocks, peers and servers. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 13.65.88.161
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 13.65.88.161 | 0.610 | 1.070 | 1.593 | 17.506 | 75.487 | 88.789 | 91.645 | 73.894 | 87.719 | 24.842 | 25.137 | ms | 0.9428 | 2.682 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 133.243.238.243
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 133.243.238.243 | 1.350 | 1.515 | 2.060 | 3.408 | 51.918 | 77.570 | 89.491 | 49.857 | 76.055 | 15.523 | 8.803 | ms | 1.715 | 7.753 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 166.70.136.35
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 166.70.136.35 | 0.171 | 0.213 | 0.317 | 0.563 | 43.094 | 65.354 | 89.423 | 42.777 | 65.140 | 14.646 | 5.899 | ms | 1.016 | 6.79 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 17.253.2.125
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 17.253.2.125 | 0.211 | 0.338 | 0.449 | 1.111 | 44.540 | 70.619 | 72.541 | 44.091 | 70.281 | 14.334 | 5.832 | ms | 1.374 | 7.707 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 17.254.0.49
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 17.254.0.49 | 0.182 | 0.266 | 0.336 | 0.812 | 53.869 | 63.771 | 76.655 | 53.533 | 63.505 | 14.672 | 8.482 | ms | 1.07 | 5.524 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 192.168.254.55
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 192.168.254.55 | 17.405 | 21.852 | 34.402 | 61.375 | 112.491 | 131.348 | 168.284 | 78.089 | 109.496 | 23.726 | 66.039 | µs | 11.99 | 40.52 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 194.58.200.20
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 194.58.200.20 | 0.102 | 0.177 | 0.228 | 0.438 | 64.839 | 69.137 | 74.766 | 64.612 | 68.960 | 17.293 | 6.718 | ms | 0.7723 | 5.195 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 199.102.46.72
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 199.102.46.72 | 0.376 | 0.416 | 0.747 | 33.608 | 61.574 | 68.210 | 70.055 | 60.827 | 67.795 | 16.989 | 33.342 | ms | 3.755 | 8.68 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 209.165.131.20
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 209.165.131.20 | 0.133 | 0.236 | 0.383 | 1.743 | 33.878 | 66.253 | 68.666 | 33.495 | 66.018 | 12.854 | 5.591 | ms | 1.628 | 8.849 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 209.193.63.10
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 209.193.63.10 | 0.154 | 0.178 | 0.242 | 0.467 | 65.007 | 91.606 | 93.003 | 64.765 | 91.428 | 21.884 | 9.520 | ms | 0.4723 | 4.013 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 209.193.63.100
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 209.193.63.100 | 0.061 | 0.134 | 0.221 | 0.475 | 35.203 | 56.442 | 56.811 | 34.982 | 56.308 | 12.418 | 5.092 | ms | 0.846 | 5.556 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 209.193.63.123
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 209.193.63.123 | 0.089 | 0.124 | 0.179 | 0.397 | 56.467 | 79.346 | 85.965 | 56.288 | 79.222 | 17.411 | 6.767 | ms | 0.8634 | 5.828 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 216.218.254.202
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 216.218.254.202 | 0.086 | 0.151 | 0.259 | 0.498 | 56.703 | 85.402 | 160.830 | 56.444 | 85.251 | 18.802 | 6.389 | ms | 1.742 | 15.08 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 31.207.56.54
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 31.207.56.54 | 0.276 | 0.337 | 0.409 | 0.699 | 47.133 | 70.445 | 91.641 | 46.724 | 70.108 | 15.162 | 5.921 | ms | 1.309 | 8.594 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Peer Jitter 31.207.56.55
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Peer Jitter 31.207.56.55 | 0.247 | 0.268 | 0.407 | 0.715 | 55.577 | 64.303 | 68.655 | 55.170 | 64.034 | 15.828 | 6.323 | ms | 0.8075 | 5.035 | |||
This shows the RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Refclock RMS Jitter SHM(0)
.png)
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Refclock RMS Jitter SHM(0) | 0.222 | 0.414 | 0.604 | 1.723 | 4.296 | 5.760 | 9.514 | 3.691 | 5.345 | 1.175 | 1.978 | ms | 3.701 | 12.1 | |||
This shows the RMS Jitter of a local refclock. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Refclock RMS Jitter SHM(1)
.png)
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Refclock RMS Jitter SHM(1) | 235.455 | 256.209 | 275.336 | 400.708 | 568.214 | 592.158 | 618.141 | 292.878 | 335.949 | 97.145 | 402.033 | µs | 40.62 | 161.8 | |||
This shows the RMS Jitter of a local refclock. Jitter is the current estimated dispersion; the variation in offset between samples.
Closer to 0s is better. An ideal system would be a horizontal line at 0s.
RMS Jitter is field 8 in the peerstats log file.
Summary
| Percentiles...... | Ranges...... | Skew- | Kurt- | ||||||||||||||
| Name | Min | 1% | 5% | 50% | 95% | 99% | Max | 90% | 95% | StdDev | Mean | Units | ness | osis | |||
| Local Clock Frequency Offset | 115.436 | 115.497 | 115.555 | 115.791 | 115.935 | 115.978 | 116.049 | 0.380 | 0.481 | 0.117 | 115.768 | ppm | 9.576e+08 | 9.438e+11 | |||
| Local Clock Time Offset | -474.704 | -451.747 | -435.970 | -12.489 | 375.710 | 462.403 | 509.922 | 811.680 | 914.150 | 288.094 | -0.115 | µs | -4.15 | 9.24 | |||
| Local RMS Frequency Jitter | 61.177 | 63.772 | 65.618 | 70.038 | 75.524 | 76.868 | 79.317 | 9.906 | 13.096 | 2.976 | 70.284 | ppb | 1.163e+04 | 2.646e+05 | |||
| Local RMS Time Jitter | 400.417 | 416.193 | 429.520 | 467.885 | 503.632 | 514.205 | 526.344 | 74.112 | 98.012 | 22.635 | 467.091 | µs | 7629 | 1.51e+05 | |||
| Peer Jitter 13.65.88.161 | 0.610 | 1.070 | 1.593 | 17.506 | 75.487 | 88.789 | 91.645 | 73.894 | 87.719 | 24.842 | 25.137 | ms | 0.9428 | 2.682 | |||
| Peer Jitter 133.243.238.243 | 1.350 | 1.515 | 2.060 | 3.408 | 51.918 | 77.570 | 89.491 | 49.857 | 76.055 | 15.523 | 8.803 | ms | 1.715 | 7.753 | |||
| Peer Jitter 166.70.136.35 | 0.171 | 0.213 | 0.317 | 0.563 | 43.094 | 65.354 | 89.423 | 42.777 | 65.140 | 14.646 | 5.899 | ms | 1.016 | 6.79 | |||
| Peer Jitter 17.253.2.125 | 0.211 | 0.338 | 0.449 | 1.111 | 44.540 | 70.619 | 72.541 | 44.091 | 70.281 | 14.334 | 5.832 | ms | 1.374 | 7.707 | |||
| Peer Jitter 17.254.0.49 | 0.182 | 0.266 | 0.336 | 0.812 | 53.869 | 63.771 | 76.655 | 53.533 | 63.505 | 14.672 | 8.482 | ms | 1.07 | 5.524 | |||
| Peer Jitter 192.168.254.55 | 17.405 | 21.852 | 34.402 | 61.375 | 112.491 | 131.348 | 168.284 | 78.089 | 109.496 | 23.726 | 66.039 | µs | 11.99 | 40.52 | |||
| Peer Jitter 194.58.200.20 | 0.102 | 0.177 | 0.228 | 0.438 | 64.839 | 69.137 | 74.766 | 64.612 | 68.960 | 17.293 | 6.718 | ms | 0.7723 | 5.195 | |||
| Peer Jitter 199.102.46.72 | 0.376 | 0.416 | 0.747 | 33.608 | 61.574 | 68.210 | 70.055 | 60.827 | 67.795 | 16.989 | 33.342 | ms | 3.755 | 8.68 | |||
| Peer Jitter 209.165.131.20 | 0.133 | 0.236 | 0.383 | 1.743 | 33.878 | 66.253 | 68.666 | 33.495 | 66.018 | 12.854 | 5.591 | ms | 1.628 | 8.849 | |||
| Peer Jitter 209.193.63.10 | 0.154 | 0.178 | 0.242 | 0.467 | 65.007 | 91.606 | 93.003 | 64.765 | 91.428 | 21.884 | 9.520 | ms | 0.4723 | 4.013 | |||
| Peer Jitter 209.193.63.100 | 0.061 | 0.134 | 0.221 | 0.475 | 35.203 | 56.442 | 56.811 | 34.982 | 56.308 | 12.418 | 5.092 | ms | 0.846 | 5.556 | |||
| Peer Jitter 209.193.63.123 | 0.089 | 0.124 | 0.179 | 0.397 | 56.467 | 79.346 | 85.965 | 56.288 | 79.222 | 17.411 | 6.767 | ms | 0.8634 | 5.828 | |||
| Peer Jitter 216.218.254.202 | 0.086 | 0.151 | 0.259 | 0.498 | 56.703 | 85.402 | 160.830 | 56.444 | 85.251 | 18.802 | 6.389 | ms | 1.742 | 15.08 | |||
| Peer Jitter 31.207.56.54 | 0.276 | 0.337 | 0.409 | 0.699 | 47.133 | 70.445 | 91.641 | 46.724 | 70.108 | 15.162 | 5.921 | ms | 1.309 | 8.594 | |||
| Peer Jitter 31.207.56.55 | 0.247 | 0.268 | 0.407 | 0.715 | 55.577 | 64.303 | 68.655 | 55.170 | 64.034 | 15.828 | 6.323 | ms | 0.8075 | 5.035 | |||
| Peer Offset 13.65.88.161 | -5.477 | -0.812 | 0.492 | 2.716 | 4.878 | 5.720 | 5.780 | 4.387 | 6.531 | 1.379 | 2.687 | ms | 2.953 | 9.808 | |||
| Peer Offset 133.243.238.243 | -3.148 | -3.037 | -2.675 | 1.288 | 5.479 | 5.786 | 5.917 | 8.153 | 8.824 | 1.833 | 1.329 | ms | -0.6802 | 5.18 | |||
| Peer Offset 166.70.136.35 | -1.856 | -1.634 | -0.999 | 1.550 | 4.095 | 4.743 | 5.128 | 5.093 | 6.377 | 1.421 | 1.471 | ms | 0.231 | 2.998 | |||
| Peer Offset 17.253.2.125 | -2.824 | 0.326 | 0.615 | 1.305 | 2.236 | 2.669 | 3.028 | 1.621 | 2.343 | 0.578 | 1.320 | ms | 4.212 | 20.02 | |||
| Peer Offset 17.254.0.49 | 0.594 | 0.708 | 0.984 | 1.636 | 2.451 | 2.690 | 2.715 | 1.468 | 1.982 | 0.437 | 1.667 | ms | 30.88 | 114.9 | |||
| Peer Offset 192.168.254.55 | 1.286 | 1.300 | 1.335 | 1.405 | 1.496 | 1.517 | 1.523 | 0.161 | 0.217 | 0.048 | 1.409 | ms | 2.28e+04 | 6.481e+05 | |||
| Peer Offset 194.58.200.20 | -1.119 | -1.066 | -0.971 | -0.614 | -0.121 | 0.019 | 0.143 | 0.850 | 1.085 | 0.251 | -0.588 | ms | -46.95 | 189.6 | |||
| Peer Offset 199.102.46.72 | -34.723 | -19.959 | -1.953 | -1.164 | -0.519 | -0.330 | -0.266 | 1.433 | 19.628 | 3.012 | -1.603 | ms | -15.91 | 137 | |||
| Peer Offset 209.165.131.20 | -3.688 | -3.484 | -2.834 | -0.419 | 1.960 | 3.328 | 4.292 | 4.794 | 6.812 | 1.493 | -0.448 | ms | -5.89 | 14.78 | |||
| Peer Offset 209.193.63.10 | 0.311 | 0.453 | 0.629 | 1.481 | 2.480 | 5.369 | 8.577 | 1.851 | 4.917 | 0.879 | 1.572 | ms | 6.484 | 40.13 | |||
| Peer Offset 209.193.63.100 | 0.814 | 0.856 | 1.091 | 1.631 | 2.237 | 2.410 | 2.511 | 1.146 | 1.553 | 0.367 | 1.627 | ms | 51.02 | 214.7 | |||
| Peer Offset 209.193.63.123 | 0.797 | 0.892 | 0.996 | 1.353 | 1.869 | 2.161 | 2.325 | 0.873 | 1.269 | 0.260 | 1.396 | ms | 97.58 | 498 | |||
| Peer Offset 216.218.254.202 | 0.350 | 0.482 | 0.579 | 1.319 | 2.847 | 3.063 | 3.234 | 2.268 | 2.581 | 0.772 | 1.596 | ms | 4.826 | 11.62 | |||
| Peer Offset 31.207.56.54 | -0.349 | 0.048 | 0.207 | 0.732 | 1.205 | 1.384 | 1.502 | 0.998 | 1.335 | 0.311 | 0.729 | ms | 6.355 | 16.39 | |||
| Peer Offset 31.207.56.55 | -0.517 | -0.235 | 0.015 | 0.685 | 1.221 | 1.476 | 1.583 | 1.206 | 1.711 | 0.366 | 0.660 | ms | 2.729 | 6.426 | |||
| Refclock Offset SHM(0) | -22.349 | -17.520 | -13.372 | -3.344 | 6.506 | 9.209 | 14.215 | 19.878 | 26.729 | 6.189 | -3.179 | ms | -8.131 | 22.17 | |||
| Refclock Offset SHM(1) | -474.705 | -451.748 | -435.971 | -12.490 | 375.711 | 462.404 | 509.923 | 811.682 | 914.152 | 288.094 | -0.115 | µs | -4.15 | 9.24 | |||
| Refclock RMS Jitter SHM(0) | 0.222 | 0.414 | 0.604 | 1.723 | 4.296 | 5.760 | 9.514 | 3.691 | 5.345 | 1.175 | 1.978 | ms | 3.701 | 12.1 | |||
| Refclock RMS Jitter SHM(1) | 235.455 | 256.209 | 275.336 | 400.708 | 568.214 | 592.158 | 618.141 | 292.878 | 335.949 | 97.145 | 402.033 | µs | 40.62 | 161.8 | |||
Back to Tech Solvency
Glossary:
- frequency offset:
- The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
- jitter, dispersion:
- The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Peer Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
- kurtosis, Kurt:
- The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
- ms, millisecond:
- One thousandth of a second = 0.001 seconds, 1e-3 seconds
- mu, mean:
- The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
- ns, nanosecond:
- One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
- percentile:
- The value below which a given percentage of values fall.
- ppb, parts per billion:
- Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
- ppm, parts per million:
- Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
- ‰, parts per thousand:
- Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
- refclock:
- Reference clock, a local GPS module or other local source of time.
- remote clock:
- Any clock reached over the network, LAN or WAN. Also called a peer or server.
- time offset:
- The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
- σ, sigma:
- Sigma denotes the standard deviation (SD) and is centered on the
arithmetic mean of the data set. The SD is simply the square root of
the variance of the data set. Two sigma is simply twice the standard
deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points. - skewness, Skew:
- The skewness of a random variable X is the third standardized
moment and is a dimension-less ratio. ntpviz uses the Pearson's moment
coefficient of skewness. Wikipedia describes it best: "The qualitative
interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero. - upstream clock:
- Any remote clock or reference clock used as a source of time.
- µs, us, microsecond:
- One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.
